Second-Hand Connecting Rods | Repair of Connecting Rods | Reconditioning of Connecting Rods – RA Power Solutions

Connecting rods of high capacity, main and auxiliary engines are repaired by RA Power Solutions. Connecting rods during the operation of the engine are heavily stressed, transmitting power generated in the combustion chamber to the crankshaft. It is important that periodically or at the time of general overhauling, the condition of the connecting rod is checked, and either it is replaced or connecting rod is reconditioned.

Inspection of Crankshaft is in Process
Inspection of Crankshaft is in Process

RA Power Solutions has four decades of experience in reconditioning of connecting rods up to the bore size of 500 mm.

Following process is adopted for successful reconditioning of connecting rods:

  • Connecting rod is subject to chemical cleaning and shot blasting after dismantling.
  • The big end and small end bore of connecting rod are checked and recorded
  • Connecting rod is checked for cracks and overheating by MPI or Dye penetrant test.
  • The serration of the joining face connecting rod bolts are also subject to crack detection.
  • Center to center distance of big end bore and small end bore is also checked.
  • Straightness of connecting rod is also checked.
Inspection of Connecting Rod
Inspection of Connecting Rod
Inspection after Reconditioning of Connecting Rods
Inspection after Reconditioning of Connecting Rods

The connecting rod’s big end and small end are re-machined/bored on the latest design of the boring machine equipped with DRDO. All the connecting rods repaired by us are guaranteed for satisfactory performance and are 100% check for quality.

Second hand connecting rods of CAT 3616 engine
Second-hand connecting rods of CAT 3616 engine
Second hand connecting rods of MAK engine in stock
Second-hand connecting rods of MAK engine in stock

We also maintain a large stock of repaired connecting rods which are reconditioned strictly as per the manufacturer’s specifications and tolerance. Generally, the cost of a reconditioned connecting rod is ¼ of the connecting rods sold by engine manufacturers.
We maintain the stock of connecting rod for the following engines:

Wartsila, Daihatsu, MWM, Caterpillar, Man, Mak, B&W, Sulzer, Bergen, Detroit Diesel, Stork Werkspoor, Pielstick, Deutz, Yanmar, MTU, Cummins, Nohab Polar, Caterpillar, Mitsubishi, Yanmar, Mak 551, Mak 552, Mak 453, Mak 451 AK , Mak 452 AK, Deutz 540 , Deutz 358 , Deutz 350, Pielstick PC 2.2 PC 2.5, Wartsila 524, Wartsila 824 TS, Sulzer 6 AL 25/30, Sulzer 5 AL 25/30 MWM TBD 484, MaN 40/54 , Man Sulzer 12 ASV 25/30, Sulzer 16 ZV 40/48, Deutz BV 16M 540, B&W 6L 45 GFCA, MAN B&W 55/GF, CAT D353, B&W 5T23LH, Daihatsu 6 PST 26D, Daihatsu 6 PSHTb 26M, Mak 6MU 451 AK, Deutz 6M 628, Caterpillar 3512, Deutz BV 12M 628, MWM TBD 234, WICHMANN 5AX, SKL 8NVD 48A-2U, Pielstick PC 2.2 LNR, Caterpillar 3508 and more.

Second hand connecting rods of Wartsila Engine
Second-hand connecting rods of Wartsila Engine
Connecting rods under inspection
Connecting rods under inspection

The author of the blog is Mr. Raj Shahani, Managing Director of the company. He is having 44 years of experience in providing new and reconditioned marine engine spares like connecting rod, cylinder liners, cylinder head, crankshaft, heat exchangers, gaskets, camshaft, white metal bearings, and many more.

For more information regarding engine connecting rods, bearings for Daihatsu engine, bearings for Yanmar engine, and new and reconditioned engine spares with the guarantee, please email us at rajshahani@rapowersolutions.com or info@rapowersolutions.com, or call us at +91 9582647131 or +91 9810012383.

Connecting rods of high capacity, main and auxiliary engines are repaired by RA Power Solutions. Connecting rods during the operation of the engine are heavily stressed, transmitting power generated in the combustion chamber to the crankshaft. It is important that periodically or at the time of general overhauling, the condition of the connecting rod is … Continue reading “Second-Hand Connecting Rods | Repair of Connecting Rods | Reconditioning of Connecting Rods – RA Power Solutions”

Repair of Connecting Rod for High Capacity Engine – RA Power Solutions

The connecting rod of a high-capacity marine engine requires periodic calibration. The marine and power industry has experienced serious accidents due to the failure of connecting rods. Some of the accidents due to failure of the connecting rods have even resulted in complete damage of the engine.

RA Power Solutions has undertaken reconditioning and repair of connecting rods, mainly of high-capacity engines for the last 4 decades of Wartsila, Caterpillar Engine, MAK, MAN, Mitsubishi, Yanmar, Pielstick, Deutz, etc.

We are following procedure for repair of connecting rods:

  • We thoroughly clean the connecting rods with special chemicals to remove oil and dirt.
  • We visually check the connecting rod for any signs of overheating, which may appear as a “bluish” discoloration. In such cases, we check the hardness and perform MPI to detect cracks in the overheated area.
Calibration of Connecting Rod is in Process
Calibration of Connecting Rod is in Process
  • A qualified technician performs the magnetic particle test under the supervision of a senior engineer. They check the serration, connecting rod bolt, bolt seating area, and the complete connecting rod for cracks. We do not accept any connecting rod with cracks.
  • We check the connecting rod bolts for elongation. If we find any deviation, we replace the bolts.
  • We tighten the connecting rod big end bolt according to the torque specified by the manufacturer.
  • Check the big end bore for taper and ovality. We also look at the bore to see whether it is damaged.
  • We inspect the small end bore for taper, ovality, or any visual damage.
  • Connecting rod is subject to shot blasting.
  • The first step for repair is to lap the serrations to the minimum, in order to bring the bore size to minus with enough allowance for internal grinding. For this special purpose machine is used.
  • We replace the small end bush with a new one if the taper or ovality is on the higher side.
  • We place the connecting rod on our boring machine equipped with the latest generation of DRDO. We then check the straightness of the connecting rod.
  • We do not recommend use of any connecting rod which has lost its alignment. No deviation is accepted and it is not recommended to straighten the connecting rod.
  • We bore the big end and small end simultaneously. This process not only maintains the taper and ovality of both bores but also ensures the center distance between them is accurate.
  • All the sharp edges are removed after boring operation.
  • We again perform a dimensional inspection of the connecting rod. We record all the readings.
  • While returning the connecting rod, proper packing is ensured.

Why Recondition with RA Power Solutions?

  • Unmatched Expertise: Four decades of proven experience in marine engine component repairs
  • Cost Savings: Reconditioned rods cost a fraction of new OEM parts—typically ¼ to ⅓ the price
  • As-Good-As-New Performance: Thorough inspection and repair guarantee performance on par with new rods
  • Strict Safety Standards: Any rod with alignment deviation or cracks is rejected—safety first
Inspection of Connecting Rod is in Process
Inspection of Connecting Rod is in Process

For more information on connecting rod repair, reconditioning of connecting rods, engine connecting rods, connecting rod replacement, and repair of connecting rods, contact us at rajshahani@rapowersolutions.com or info@rapowersolutions.com, or call us at +91 9582647131 or +91 9810012383.

FAQs:

1. What causes damage to a connecting rod?

Damage can occur due to overheating, lack of lubrication, excessive engine load, or metal fatigue over time.

2. Can a damaged connecting rod be repaired instead of replaced?

Yes. If there are no cracks and the geometry is restorable, our technicians can recondition the connecting rod to OEM specifications, saving significant costs compared to buying a new one.

3. How do you check for cracks in a connecting rod?

We perform Magnetic Particle Inspection (MPI) under the supervision of a senior engineer to detect even the smallest cracks in the serrations, bolts, bolt seating area, and the rod body.

4. What happens if the small end or big end is out of tolerance?

We bore both ends simultaneously to correct taper and ovality, ensuring the correct center distance between them. If required, we replace the small end bush.

5. Do you provide connecting rod repair services on-site?

Yes. We can perform inspections and certain repairs at the client’s site, and we also have a fully equipped workshop for complete reconditioning.
